InSync RD - RFID - Deadbolt Multihousing Door Smart Lock RD01 RD03

In stock
SKU: LOCSAFRD01-26D
$301.50
Configuration
Finish

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Note: These items have very limited availability in stock, call us to place your order.

Customize Your Smart Lock – Tailored to Fit Your Needs

Due to the customizable nature of this product, we recommend contacting us directly to begin your order. Our team will help you select the right configuration and ensure compatibility with your existing setup.

Call us at 801-972-4331 if you have any questions or would like help choosing the correct lock for your situation.


Notes:

All InSync locks are designed for doors ranging from 1 ⅜” to 2” thick. For door sizes outside this range, custom parts will be required.

Features:

Amenity that reduces liability, costs, and improves property operations

  • RFID keys (purchased separately) are encrypted with unique coding that cannot be duplicated

  • Unlike traditional keys, RFID keys cannot be copied

  • When the lever is depressed, both the deadbolt and cylindrical latchbolt are simultaneously retracted

  • Solves the master key problem – if master RFID key is lost or stolen, simply program a new one.  That new master RFID key when inserted in locks “instructs” the locks to then only accept that new master RFID key

  • Solves the turnover issue of having to change locks/re-key.  Simply program a new RFID key for incoming resident

  • One RFID key can open residents units, as well as common area including fitness center, laundry, parking garage, etc.

  • Property manager and maintenance staff can have one RFID key for all tenant and common use doors

  • Specify the times using intuitive SAM Software (purchased separately) for when maintenance personnel keys are allowed to gain access

  • RFID keys work until pre-programmed specific times, and each new RFID key cancels out previous RFID keys which may have been lost or misplaced

  • Centralized control; no need to reprogram locks with device at the lock, simply reprogram the RFID key using the RF key encoder (available at checkout)

  • Intuitive, easy-to-use windows-based software for centralized management of user information, openings, as well as audit trail reporting

  • Custom finishes available, including bright brass, dark mahogany, satin brass, and bright chrome

  • Gala Lever Design

Specs:

  • 1″ deadbolt – lock via manual thumbturn from inside.  Lock by inserting and rotating RFID key when exiting

  • Complete interconnected lever set

  • 4-1/2″ center to center distance between the 2-1/8″ diameter door holes

  • Backset:  Standard 2 3/8″ with 1″ faceplate supplied, 2 3/4″ backsets available upon request, along with 4-7/8″ strikes

  • Battery operation:  4 AA’s

Environmental:

Indoor/outdoor approval: -31 ºF to 151 ºF (-35 ºC to 66 ºF). Locking Device Option 0 meets FL Windstorm Specification. Certified compliance to the Florida Building Code per FL13061.1 for installation in HVHZ (High Velocity Hurricane Zone) areas for mortise with deadbolt and auto deadbolt locking devices only.  (Refer to FloridaBuilding.org for actual product approvals and specifications)

Compatibility:

Works with SAM-RF® Software and Insync™ Programmers/ Encoders

Saflok® Insync™ RFID KEYs are used to open these locks.



Additional Documentation:

insync-d-data-sheet

insync-d-cylindrical-deadbolt-adjustment

insync-d-deadbolt-drill-template

Check the DormaKaba website for the most up-to-date information about the Insync D Series locks.
